Description
This battery is a dedicated battery, designed exclusively for the CADDXFPV PROTOS Drone. Do not use it for any other purposes.
Specifications.
Specifications.
- Model C0PJ-DC016
- FCC IC 2BHG9-C0PJ-DC016
- Battery Type Li-ion (Lithium-ion Battery)
- Battery Capacity 840mAh
- Battery Specification 2S1P (2 Cells in Series, 1 in Parallel)
- Discharge Rate (C-Rate) 15C
- Maximum Power 6.384Wh
- Voltage Range 6.80V~8.70V
- Max Charging Voltage 8.5V
- Charging Method 2S Charger
- Charging Time ≤20min
- Protection Mechanism When the voltage of a single cell drops below 2.8V,battery lock protection is triggered and charging is required to reactivate.
- Dimensions 77.5x24x21mm
- Weight 41.9g±0.5g
